ALU-STOP BN-A
high temperature release and lubricating agent
• for use on metals, ceramics, fibre ceramics and graphite
• produces non-wetting surfaces
• for metal melts such as aluminium and magnesium, zinc and lead
• for pressing and high pressure sintering of hard metal powders
• ready for use aerosol for an easy application
• contains "white graphite"

Description

ALU-STOP BN-A Boron Nitride Aerosol is a special coating material based on high-purity boron nitride showing a high specific surface. This coating shows an excellent non-wetting behaviour against most metal metals and can be applied directly onto the substrate to be protected. By the use of quick-drying components the coating can be put into service after a short drying time. ALU-STOP BN-A Boron Nitride Aerosol enables an easy and quick application in research facilities as well as in the production.

Application

• Remove dust and remains of melts etc. from the surface to be coated.
• Shake can well before use.
• Spray from a distance of 20 cm (8").
• Best results are achieved by even movements when spraying.
• Apply thin coatings. Thick coatings may may crack upon drying.
• Additional layers may be applied after drying.

Storage-Container Size

Container is under pressure. Protect against sunlight and temperatures exceeding 50°C (122°F). ALU-STOP BN-A Boron Nitride Aerosol is available in containers of 500ml.

Safety Advices

ALU-STOP BN-A Boron Nitride Aerosol contains ethanol (ethyl alcohol) and propane/butane and is labelled extremely flammable. Use only in well ventilated areas. This product does not contain chlorofluorocarbons (CFC) or clorinated hydrocarbons. An EC material safety data sheet is available.

Technical Data

Colour

white

Ceramic Constituent

Boron nitride

Solvent

Ethanol (ethyl alcohol)

Propellent gas

Propane/Butane

Density

0.8 g/cm³

Temperature (max. Application)

1000°C (1832°F) (at air)

1800°C (3272°F) (under inert gas)




© 2015 Büro für angewandte Mineralogie · Dr. Stephan Rudolph · D-47918 Tönisvorst


These recommendations are believed to be correct. However, no guarantee of their accuracy is given. Therefore, purchasers shall make their own tests to determine suitability for their use. These products are offered for industrial and related uses (e.g. research and development) only. However the user must take the necessary precautions appropriate for products containing chemicals. This description does not imply the absence of any patents, the responsibility whatsoever solely rests with the user.
