Graphite Aerosol GS
• high temperature release and lubricating agent
• for use on metals, ceramics and graphite
• produces lubricating, non-wetting surfaces
• good electrical and thermal conductivity
• shows best parting characteristics and is chemically stable
• release agent for the metallurgy and high pressure sintering techniques
• ready for use aerosol for an easy application

Description

Graphite Aerosol GS is a coating based on special graphites for best release and lubrication characteristics. Due to its extremely good high temperature lubrication properties it finds application as a parting agent in the metallurgy and for sinterng and high-pressure sintering as well as for the lubrication of chain conveyors and conveying belts in the high-temperature area.

Application

• Remove dust and remains of melts etc. from the surface to be coated.
• Shake can well before use.
• Spray from a distance of 20 cm (8").
• Best results are achieved by even movements when spraying.
• Apply thin coatings. Thick coatings may may crack upon drying.
• Additional layers may be applied after drying.

Storage-Container Size

Container is under pressure. Protect against sunlight and temperatures exceeding 50°C (122°F). Graphite Aerosol GS is available in containers of 400ml.

Safety Advices

Graphite Aerosol GS contains 2-propanol (isopropyl alcohol) and propane/butane and is labelled extremely flammable. Use only in well ventilated areas. This product does not contain chlorofluorocarbons (CFC) or clorinated hydrocarbons. An EC material safety data sheet is available.

Technical Data

Colour

Black

Ceramic Constituent

Graphite

Solvent

2-Propanol (isopropyl alkohol)

Propellent gas

Propane/Butane

Density

0.8 g/cm³

Temperature (max. Application)

400°C (752°F) (at air)

1800°C (3272°F) (under inert gas)




© 2015 Büro für angewandte Mineralogie · Dr. Stephan Rudolph · D-47918 Tönisvorst


These recommendations are believed to be correct. However, no guarantee of their accuracy is given. Therefore, purchasers shall make their own tests to determine suitability for their use. These products are offered for industrial and related uses (e.g. research and development) only. However the user must take the necessary precautions appropriate for products containing chemicals. This description does not imply the absence of any patents, the responsibility whatsoever solely rests with the user.
